Short Description:

• ● Place of Origin: Jiangsu, China (Mainland):

• ● Material: Carbide

• ● Diameter: 1-20mm:

• ● Flute Number: 2/3/4 and comsized

• ● Overall Length: 50-150mm:

• ● OEM: Available

• ● Surface: Ticn/Tin/Tiain/Uncoated:

• ● Size: Customers Requirements

• ● Application: CNC Process:

• ● Controlling Mode: CNC Tooling System

• ● Processing Type: Metal Cutting Tools:

• ● Usage: General High Speed Cutting

• ● Suitable for: Carbon Steel:

• ● Port: Shanghai

• ● Payment Terms: : Western Union, Paypal, D/A, D/P, T/T

• ● Delivery Time: : 7-10 Working Days

• ● Packing: Carton:

• ● Express: Fedex,DHL,EMS

• Specifications of Flat End Mill (mm)	Cutting	Cutting Length	Shank	A.O.L	Flute
  	d	l	D	L	F
  1.0×2.5×4D×50L×4F	1	2.5	4	50	4F
  1.5×3.75×4D×50L×4F	1.5	3.75	4	50	4F
  2.0×5.0×4D×50L×4F	2	5	4	50	4F
  2.5×6.25×4D×50L×4F	2.5	6.25	4	50	4F
  3.0×7.5×4D×50L×4F	3	7.5	4	50	4F
  3.5×8.75×4D×50L×4F	3.5	8.75	4	50	4F
  4.0×10×4D×50L×4F	4	10	4	50	4F
  5.0×12.5×5D×50L×4F	5	12.5	5	50	4F
  5.0×12.5×6D×50L×4F	5	12.5	6	50	4F
  6.0×15×6D×50L×4F	6	15	6	50	4F
  8.0×20×8D×60L×4F	8	20	8	60	4F
  9.0*20*10D*75L*4F	9	20	10	75	4F
  10.0×25×10D×75L×4F	10	25	10	75	4F
  12.0×30×12D×75L×4F	12	30	12	75	4F
  14.0×35×14D×100L×4F	14	35	14	100	4F
  16.0×40×16D×100L×4F	16	40	16	100	4F
  18.0×45×18D×100L×4F	18	45	18	100	4F
  20.0×50×20D×100L×4F	20	50	20	100	4F

•


Product Detail:
